3 Product description
Maschinenfabrik Reinhausen 2014 23222/08 EN TAPCON® 240
Figure 9: SUL-P card
Voltage measurement and current measurement
To measure voltage and current, the device can be equipped with the as-
sembly MI or MI3-G:
▪ MI: 1-phase measurement of voltage and current
▪ MI3-G: 3-phase measurement of voltage and current
Only connect the MI card to one current transformer, otherwise the current
measurement will not work.
Figure 10: MI-1 card
3.5.5.2
