3 Product description
Maschinenfabrik Reinhausen 2014 29222/08 EN TAPCON® 240
Figure 20: CIC card
1 RS232 6 TxD LED for transmit signal
2 RS485 7 RxD LED for receive signal
3 RJ45 (Ethernet), optional 8 Clk LED for operating mode
(flashes for 2 seconds)
4 Fiber-optic cable, optional 9 Clip for connecting cable
shield
5 Reset key
