MR tapcon 240 - Page 34

5 Mounting
Maschinenfabrik Reinhausen 201434 222/08 ENTAPCON® 240
Cable Card Terminal Cable type Conductor
cross-sec-
tion
Max. length
Power supply SU X1:1/2 Unshielded 1.5 mm² -
Voltage
measurement
MI/MI1 1/2 Shielded 1.5 mm² -
Current
measurement
MI/MI1 5/6/9/10 Unshielded 4 mm² -
Relay* IO X1:1...10
X1:19...26
Unshielded 1.5 mm² -
Relay* UC X1:1...10 Unshielded 1.5 mm² -
Signal inputs IO X1:11...17
X1:27...34
Shielded 1.0 mm² -
Signal inputs UC X1:11...17
X1:27...34
Shielded 1.0 mm² -
CAN bus CPU 1...5 Shielded 1.0 mm² 2000 m
Table 7: Recommendation for connection cable (standard connections)
*) Observe line capacitance, see note above.
Cable Card Terminal Cable type Conductor
cross-sec-
tion
Max. length
AC AC X1/2:1/2 Unshielded 1.5 mm² -
Analog inputs AD8 X1:1...3 Shielded 1.5 mm² 400 m (< 25 Ω/km)
Analog out-
puts
AN/AN1 X1 Shielded 1mm² -
RS-232 CIC X8 Shielded 0.25 mm² 25 m
RS-485 CIC X9 Shielded 0.75 mm² 1000 m (< 50 Ω/km)
Ethernet SID
CIC
RJ45
X7
shielded, CAT
7
- 100 m
Media con-
verter
MC1 - Optical fiber
with MTRJ-
ST duplex
patch cable
- -
Media con-
verter
MC2 - Fiber-optic
cable, con-
nector type:
F-ST; fiber
type: multi
mode/single
mode; wave-
length:
1310 nm
- -
Table 8: Recommendation for connection cable (optional connections)
