User’s Guide – Ultima cutting plotter
16 AP-75032, Rev 2.2, 20/04/07
10 USB interface
USB connector to easily connect the cutter for fast and reliable data
transmission.
11 Serial Interface Connector
RS-232 serial interface connector to connect the cutter to the host
computer.
12
Centronics Connector
Centronics Connector to connect the cutter to the host computer.
13 Power Connector
Connector for the power cord, which plugs into the main power
supply of the cutter.
14 Pressure Rollers
Hold the media against the drive rollers during cutting.
15 Drive Rollers
Move the cutting media along the X-axis.
16 Media Basket
Media collecting basket prevents finished cuts to fall on the floor
when they are sheet-off.
17
Cutting head for Cutting
and Sheeting Off
All available tools such as knife holders, drawing pens and painting
pens can be secured into the head using the locking screw. The tool
head moves along the Y-axis to locate the cutting position.
18 Stand
Support the Plotter Body.
19 Hold Lever
Raises and lowers the pressure rollers. Lowering the pressure rollers
will hold the media in place.
