Step 7 : Press the [ENTER] key to confirm.
Notes
If you do not want to perform the test, press the [EXIT] key.
Step 8 : The Ultima will cut following pattern.
5.6.4. Settings Plot
To plot the settings, please follow the instructions mentioned below.
Step 1 : Install a pen.
Step 2 : Press the [TOOL] key and select ‘pen’.
Step 3 : Install an A3-format paper (portrait)
Step 4 : Press the [TEST] key. The display will show the following message.
Testplot :
Quality check
→ SC-850 or SC-1400
Choose testfile
Step 5 : By pressing the [UP] or [DOWN] key select ‘Settings → plot’. The display on the operation panel
will show the following message.
Testplot :
Settings
→ Plot
Choose testfile
Step 6 : The Ultima cutting plotter will plot the actual settings.
