User’s Guide – Ultima cutting plotter
93 AP-75032, Rev 2.2, 20/04/07
IDFE_MBUSGETDATA_SEARCHSENSOR 6019 "MBUS GETDATA IN SEARCHSENSOR"
IDFE_MBUSSTOP_SEARCHSENSOR 6020 "MBUSSTOP IN SEARCHSENSOR"
IDFE_MBUSSTOP_SEARCHSENSOR1 6021 "MBUSSTOP IN SEARCHSENSOR1"
IDFE_MBUSSTOP_SEARCHSENSOR2 6022 "MBUSSTOP IN SEARCHSENSOR2"
IDFE_MBUS_CMD_SETKNIFE 6023 "PROBLEM IN SETKNIFE"
IDFE_MBUS_CMD_SETLASER 6024 "PROBLEM IN SETLASER"
IDFE_SFWT_CTF 6070 "SFWT delay_ctf problem"
IDFE_SFWT_MATCHINTU 6071 "SFWT match_intu problem"
IDFE_SFWT_DELAY 6072 "SFWT delay problem"
IDFE_MOVEABSMC 6080 "Moveabsmc problem"
IDFE_OPOS_MBUSREAD 6090 "EPOS Mbus read blocks"
IDFE_OPOS_MBUSSTOP 6091 "EPOS Mbus read blocks"
IDFE_OPOS_CALCPENTOLED_SEARCHEDGE 6092 "EPOS calc pen toled search edge blocks"
IDFE_OPOS_AUTOCALIBRATE_SEARCHEDGE 6093 "EPOS auto calibrate search edge blocks"
IDFE_OPOS_AUTOCALIBRATE_CALIBRATE1 6094 "EPOS calibrate get data blocks"
IDFE_OPOS_AUTOCALIBRATE_CALIBRATE2 6095 "CALIBRATE PROBLEM IN AUTOCALIBRATE 2"
IDFE_OPOS_CALIB_GETDATA 6096 "EPOS calibrate get data blocks"
IDFE_OPOS_CALIBRPENTOLED 6097 "EPOS calibrate pen to led blocks"
IDFE_BUMP_WRONG_MACHINE_WIDTH 6100 "BUMP PROBLEM MACHINE WIDTH"
IDFE_SHUFFLE_WRONG_MACHINE_WIDTH 6101 "SHUFFLE PROBLEM MACHINE WIDTH"
IDFE_SHUFFLE1 6105 "SHUFFLE PROBLEM1"
IDFE_SHUFFLE2 6106 "SHUFFLE PROBLEM2"
IDFE_SHUFFLE3 6107 "SHUFFLE PROBLEM3"
IDFE_SHUFFLE4 6108 "SHUFFLE PROBLEM4"
IDFE_SHUFFLE5 6109 "SHUFFLE PROBLEM5"
IDFE_DRAM_OVERRUN 6111 "DRAM overrun error"
IDFE_SRAM_OVERRUN 6112 "SRAM overrun error"
6.6.3. Communication errors
Communication errors are caused by a problem in the communication between the cutter and the host
computer. They can be caused by errors related to the communication conditions, errors due to a defective
handshake or command format errors in the ESCAPE sequences.
KEYB_COMM_CHECKSUM : KEYB communication checksum problem
UART1_COMM_ERROR : UART1 communication error
UART2_COMM_ERROR : UART2 communication error
UART2_SENDTOKEYB_ERROR : UART2 send to keyb problem
6.6.4. Language errors
Language errors occur when command data entered from the host computer does not match the data
format of the command mode currently activated on the cutter’s side. The error can be caused by a
difference in command type or by a syntax error.
PGTOOSHORT : PG error : Media too short to perform a 'PG;'.
PGM0TOOSHORT : PG Mode 0 Error : Media too short to perform a 'PG;'.
PGM1TOOSHORT : PG Mode 1 Error : Media too short to perform a 'PG;'.
PGM2TOOSHORT : PG Mode 2 Error : Media too short to perform a 'PG;'.
DRAWERROR00 : Out of limit error, vector has been clipped.
Each HPGL command has its own error code with a message
