Press the [FORCE] key to access the force menu
OFFSET
Press the [OFFSET] key to access the offset adjustment menu
TOOL
Press the [TOOL] key to change the tool type.
Take-Up / Sheet / Roll
Press the [MEDIA SUPPLY TYPE] key to select how media is loaded.
ARROW-KEY
Press the [ARROW] key for manual movement of the tool head.
LIGHT INDICATORS
LED Description
ORIGIN
Blinks to indicate that you can move the head to replace the origin when you are in
the origin menu.
Lighting indicates that we have a set the origin.
Use the arrow keys to set the origin position by means of the laser led and confirm
with the enter key.
CONTOUR CUTTING
Indicates that an aligning procedure is busy.
TAKE-UP
Indicating that you are working with roll media without front edge detection
SHEET
Indicating that you are working with a sheet of media.
ROLL
Indicating that you are working with roll media using front edge detection
Caution
Please do not use sharp or pointed tools like ballpoints or pencils to press keys. The operation panel is to
be operated with your fingertips.
