User’s Guide – Ultima cutting plotter
78 AP-75032, Rev 2.2, 20/04/07
5.6.5. EPOS Align tune (Manual)
The manual calibration can be done with knife or with pen. Depending of the installed tool a test plot will be
drawn/cut.
5.6.3.1. Manual calibration with knife
To calibrate the E-pos system using the ‘manual calibration’ with knife, please follow the instructions
mentioned below.
Step 1 : Install a knife.
Step 2 : Press the [TOOL] key and select ‘knife’.
Step 3 : Install a black vinyl.
Step 4 : First set the ORIGIN in the middle of the media.
¾ Press the [Origin] key.
¾ Use the [ARROW] keys to position the tool head in the middle of the media.
¾ Press the [ENTER] key to confirm.
Step 5 : Press the [TEST] key. The display will show the following message.
Testplot :
Quality check
→ SC-850 or SC-1400
Choose testfile
Step 6 : By pressing the [UP] or [DOWN] key select ‘EPOS align tune --> manual’. The Display on the
Operation Panel will show the following message.
Testplot :
EPOS align tune
→ manual
Choose testfile
Step 7 : Press the [ENTER] key. The Ultima cutting plotter will start cutting two square boxes. After
drawing following message will appear.
Measure box is
cut please
weed out and
press a button
Step 8 : Peel off the boxes cut by the Ultima cutting plotter.
Step 9 : Press the [ENTER] key.
Step 10 : The Ultima cutting plotter will move the laser to the point where both squares touch. Following
message will appear.
* Epos Calibration. *
Please move
laser pointer to
cross and enter
