User’s Guide – Ultima cutting plotter
80 AP-75032, Rev 2.2, 20/04/07
5.6.6. EPOS Align tune (Automatic)
To calibrate the E-pos system using the ‘Automatic calibration’, please follow the instructions mentioned
below.
Step 1 : Install a knife.
Step 2 : Press the [TOOL] key and select ‘knife’.
Step 3 : Install a black vinyl.
Step 4 : Press the [TEST] key. The display will show the following message.
Testplot :
Quality check
→ SC-850 or SC-1400
Choose testfile
Step 5 : By pressing the [UP] or [DOWN] key select ‘EPOS align tune --> automatic. The Display on the
Operation Panel will show the following message.
Testplot :
EPOS align tune
→ automatic
Choose testfile
Step 6 : Press the [ENTER] key. The Ultima cutting plotter will cut a square. After cutting following
message will appear.
Measure box is
cut please
weed out and
press a button
Step 7 : Peel of the box cut by the Ultima cutting plotter.
Step 8 : Press the [ENTER] key.
Step 9 : The laser of the Ultima cutting plotter will measure the box. The distance between laser and
knife is calculated and stored.
Step 10 : Calibration of the E-pos system with the ‘automatic calibration’ method is done. Following
message will appear.
EPOS
Calibration
done
