User’s Guide – Ultima cutting plotter
79 AP-75032, Rev 2.2, 20/04/07
Step 11 : If necessary, use the [ARROW] keys to position the laser exactly onto the point where both
squares touch. Do not keep the [ARROW] keys pressed, they only causes one movement.
Step 12 : Press the [ENTER] key to confirm the position of the laser. The distance between laser and knife
is calculated and stored.
Step 13 : Calibration of the E-pos system with the ‘manual calibration’ method is done.
5.6.3.2. Manual calibration with Pen
To calibrate the E-pos system using the ‘manual calibration’ with pen, please follow the instructions
mentioned below.
Step 1 : Install a pen.
Step 2 : Press the [TOOL] key and select ‘pen’.
Step 3 : Install an A4-format paper.
Step 4 : First set the ORIGIN in the middle of the media.
¾ Press the [Origin] key.
¾ Use the [ARROW] keys to position the tool head in the middle of the media.
¾ Press the [ENTER] key to confirm.
Step 5 : Press the [TEST] key. The display will show the following message.
Testplot :
Quality check
→ SC-850 or SC-1400
Choose testfile
Step 6 : By pressing the [UP] or [DOWN] key select ‘EPOS align tune --> manual’. The Display on the
Operation Panel will show the following message.
Testplot :
EPOS align tune
→ manual
Choose testfile
Step 7 : Press the [ENTER] key. The Ultima cutting plotter will start drawing a cross.
Step 8 : The Ultima cutting plotter will move the laser to the point where both lines intersect. Following
message will appear.
* Epos Calibrate. *
Please move
laser pointer to
cross and enter
Step 9 : If necessary, use the [ARROW] keys to position the laser exactly onto the point where both lines
intersect. Do not keep the [ARROW] keys pressed, pressing the keys only causes one
movement.
Step 10 : Press the [ENTER] key to confirm the position of the laser. The distance between laser and knife
is calculated and stored.
Step 11 : Calibration of the E-pos system with the ‘manual calibration’ method is done.
