4.2.4. Max Sheet length
After installation of a sheet (and sheet is selected in the menu) the Ultima cutting plotter will measure the
width and length of the sheet.
In case sheet is selected in the menu but roll media is loaded the Ultima will measure the length of the roll.
This is not the intension. Therefore, you can select a Max Sheet length value. In case sheet is selected in
the menu, the Ultima will not measure more than the length selected in the Max Sheet length menu,
preventing roll media to be rolled off completely.
To change the value of the Max Sheet length, please follow the instructions mentioned below.
Step 1 : In the general setting select ‘Max Sheet length’ by using the [UP] or [DOWN] key.
Step 2 : Press the [ENTER] key to confirm your selection. The actual Pre-Feed Length will now be shown
on the display
Max sheet length
Actual : 5000
New : 5000
Sheet length (mm)
Step 3 : By using the [UP] or [DOWN] key select an appropriate value.
Step 4 : Press the [ENTER] key to confirm.
Notes
To cancel the changes of the parameter, press the [CANCEL] key. The display will show the previous
value for the parameter.
When you press the [EXIT] key the changed value will be ignored and you go back to the previous menu.
