User’s Guide – Ultima cutting plotter
92 AP-75032, Rev 2.2, 20/04/07
6.6.2. Unrecoverable system errors
Unrecoverable errors may be caused by some part of the cutting plotter, which is malfunctioning. In case
of an unrecoverable error, most of the time the cutter will be completely blocked and all the LEDs will be
flashing. The error id, number and description will appear on the keyboard display, and will be cleared when
entering a key.
IDFE_NOYENCODER 1000 "No Y encoder, check connectors or call service"
IDFE_YPOSENCTURN 1001 "Y+ encoder turn, check connector or call service"
IDFE_YNEGENCTURN 1002 "Y- encoder turn, check connectors or call service"
IDFE_YXSWAPPED 1004 "YX are swapped, check connectors or call service"
IDFE_NOXENCODER 1005 "No X encoder, check connectors or call service"
IDFE_XPOSENCTURN 1006 "X+ encoder turn, check connectors or call service"
IDFE_XNEGENCTURN 1007 "X- encoder turn, check connectors or call service"
IDFE_XYSWAPPED 1008 "XY are swapped, check connectors or call service"
IDFE_YPOSERROR 1009 "Y position error, PWM switched off as a safety"
IDFE_XPOSERROR 1010 "X position error, PWM switched off as a safety"
IDFE_ZPOSERROR 1011 "Z position error, PWM switched off as a safety"
IDFE_DRAMERROR0 1012 "MEMORY size allocation error"
IDFE_DRAMERROR1 1013 "MEMORY allocation lower limit error"
IDFE_DRAMERROR2 1014 "MEMORY allocation upper limit error"
IDFE_GENYENCODER 1020 "General Y encoder failure, PWM switched off"
IDFE_GENXENCODER 1030 "General X encoder failure, PWM switched off"
IDFE_SERIALOFW 1040 "Serial Buffer Overflow Error"
IDFE_VECTOROFW 1041 "Vector Buffer Overflow Error"
IDFE_SERVOOFW 1042 "Servo Buffer Overflow Error"
IDFE_NOZENCODER 1045 "No Z encoder, check connectors or call service"
IDFE_ZPOSENCTURN 1046 "Z+ encoder turn, check connectors or call service"
IDFE_ZNEGENCTURN 1047 "Z- encoder turn, check connectors or call service"
IDFE_GENZENCODER 1048 "General Z encoder failure, PWM switched off"
IDFE_RAMCARDAAAA 1200 "RamCard Error while writing 'AAAA' code"
IDFE_RAMCARD5555 1201 "RamCard Error while writing '5555' code"
IDFE_UNDEFCARD 1205 "Undefined card inserted"
IDFE_UNDEFCARDWP 1206 "Undefined card inserted and write protected"
IDFE_CORRUPTUCCA 1300 "Corrupt 'UCCA' code, Flash incorrectly loaded"
IDFE_CORRUPTFCCA 1301 "Corrupt 'FCCA' code, Flash incorrectly loaded"
IDFE_MBUS_SWMBSR_BUSY_TIMEOUT 6000 "MBUS SW BUSY timeout"
IDFE_MBUS_SWMBSR_RECV_TIMEOUT 6001 "MBUS SW RECEIVE timeout"
IDFE_MBUS_HWMBSR_MBB_TIMEOUT 6002 "MBUS HW MBB timeout"
IDFE_MBUS_HWMBSR_MIF_TIMEOUT 6003 "MBUS HW MIF timeout"
IDFE_MBUS_CMD_STOP 6004 "MBUS Stop command failed"
IDFE_MBUS_HWMBSR_MAL_ERROR 6005 "MBUS HW MAL arbitration lost error"
IDFE_MBUS_HWMBSR_ADR_RXAK_ERROR 6006 "MBUS HW RXAK no ack from slave in adr cycle"
IDFE_MBUS_HWMBSR_DATA_RXAK_ERROR 6007 "MBUS HW RXAK no ack from slave in data cycle"
IDFE_MBUS_HWMBSR_INT_MAL_ERROR 6008 "MBUS HW MAL INT arbitration losterror"
IDFE_MBUS_HWMBSR_INT_ADR_RXAK_ERROR 6009 "MBUS HW RXAK INTno ack from slv in adr cycle"
IDFE_MBUS_CMD_PIOREAD 6010 "MBUS PIO Read (POLL) command failed"
IDFE_MBUS_CMD_ADCREAD 6011 "MBUS ADC Read (POLL) command failed"
IDFE_MBUS_CMD_PIOWRITE 6012 "MBUS Piowrite command failed"
IDFE_MBUS_CMD_PIOREADI 6013 "MBUS PIO Read (INT) command failed"
IDFE_MBUS_CMD_ADCREADI 6014 "MBUS ADC Read (INT) command failed"
IDFE_MBUS_CMD_SETDATA 6015 "MBUS SetData command failed"
IDFE_MBUS_CMD_GETDATA 6016 "MBUS GetData command failed"
IDFE_MBUS_CMD_PIOSET 6017 "MBUS PIOSet command failed"
IDFE_MBUS_CMD_READ 6018 "MBUS Read command failed"
