4.3 SPECIAL KEY COMBINATIONS
ShortCut description Key combination Comment
Bar code verification Test + Contour Cutting + Right
Jog key
Position head near bar code first
Updating the keyboard Presets + Origin + Speed + Force Press all keys simultaneously after startup
Reset the keyboard Test + Contour Cutting + Offset +
tool
Press all keys simultaneously after startup
Enter / Leave
Diagnostics
Presets + Origin + Test + Contour
Cutting
Press all keys simultaneously
Enter Diagnostics before
initialisation
Presets + Test Press all keys simultaneously while second
menu screen appears (Version window)
Laser ON Test + Left Jog key Press all keys simultaneously after startup
Laser OFF Test + Right Jog key Press all keys simultaneously after startup
Black - White or White -
black detection
Contour cutting + # Jog keys Put head approximately 2cm from the B-W
or W-B edge. Press both keys
simultaneously after startup
Activate Sheet off knife Origin + Right Press all keys simultaneously after startup -
Does not perform a sheet off
Deactivate Sheet off
knife
Origin + Left Press all keys simultaneously after startup -
Does not perform a sheet off
Origin reset Origin + Sheet off Press first Origin, then press EXIT to reset
your previous origin position (always home
position)
New EPOS offset fine -
tune
Test + Contour Cutting Press both keys simultaneously -> Only
accurate for 1 job
