User’s Guide ValueJet 1608 HS
Periodical maintenance
AP-75810 - Revision 2.0 145
6
Step 2: Dip the cleaning stick in the cleaning fluid, and remove the ink and dust on the
cleaning wiper.
 Cleaning wiper left side:
Remove the ink and dust from the front and back.
 Cleaning wiper right side:
Remove the ink and dust from the front and back.
1
3
2
N° Description
1
Cleaning wiper left side
2 Cleaning stick
3 Head cap unit
1
2
N° Description
1
Cleaning wiper right side
2 Cleaning stick
