VJ-1628X OPERATION MANUAL Before using
3.6 Test print 113
20. Remove the white reference plate from the plate installation place, turn it over so that the black side
faces up, and install it back to the original place.
• When the white reference plate is not in use, make sure that it is turned over facing down to avoid
any contamination.
21. Close the maintenance cover.
No. Name
1
White reference plate
2
Plate installation place
No. Name
1
Maintenance cover
To Next Page
