VJ-1628X OPERATION MANUAL Handling the printer
4.5 Using Spectrophotometer 193
11. Remove the white reference plate from the plate installation place, turn it over so that the white side
faces up, and install it back to the original place.
• Before measuring the color target, make sure that the white side of the white reference plate is
facing up.
If the black side is facing up, it will not be measured accurately.
12. Close Maintenance cover.
• Print head moves to the right.
• “Wait for a while...” is displayed on Operation panel.
No. Name
1 White reference plate
2 Plate installation place
No. Name
1 Maintenance cover
To Next Page
