VJ-1628X OPERATION MANUAL Handling the printer
4.5 Using Spectrophotometer 195
15. Open Maintenance cover on the left of the printer.
• Detach instrument and set connector cap. [ENTER] is displayed on Operation panel.
16. While pressing the release buttons on both sides of Spectrophotometer, pull it forward to remove it
from Print head.
No. Name
1 Maintenance cover
No. Name
1 Spectrophotometer
2 Release buttons
3 Print head section
