Handling the printer VJ-1628X OPERATION MANUAL
196 4.5 Using Spectrophotometer
17. Firmly pinch the tabs on both sides of Connector cap with your fingers, and install it to the connector
of Print head.
18. Press the [Enter] key.
• “Wait for a while...” is displayed on Operation panel.
• “Remove white plate, then close left maintenance cover.” is displayed on Operation panel.
No. Name
1 Connector cap
2Tabs
3 Print head section
4 Connector
To Next Page
