MUTOH ValueJet VJ1324X - 4.2.3 Precaution on storing media; 4.2.4 Printing area; 4.2.5 Head height adjustment

Handling the printer VJ-1324X OPERATION MANUAL
110 4.2 Media
4.2.3 Precaution on storing media
Note the following points on storing media.
NOTE
• Avoid high temperature, high humidity, and direct sunlight when storing media.
• After removing the unused roll media from the scroller, wind it properly.
Then wrap it with an individual bag and store it in an individual box.
• Keep the media dry.
4.2.4 Printing area
The printable area of this printer is as follows.
4.2.5 Head height adjustment
Printing with high printing rate or using strongly-curved media can cause print heads to rub.
Changing the distance from the print head surface to media (head height) may allow you to avoid
headrub.
Head height can be changed to two levels.
Follow the procedure below to change the head height.
a
c
bd
Printable Area
a=Max. 15mm
b=5mm to 25mm
c=5mm
d=5mm to 25mm
Media feeding direction
