VJ-1324X OPERATION MANUAL Before using
3.4 Loading media 55
3.4.2 Setting Roll Media
This section explains how to set the roll media.
Follow the procedure below to set the roll media.
1. Turn the printer ON.
• Do not operate the media loading lever during the initial operation or printing.
The print head portion may touch the pressurizing roller portion, and cause a
malfunction.
• The printer starts the initializing operation.
• “Media End” is displayed on the operation panel.
2. Raise the media loading lever.
• “Lever Up” is displayed on the operation panel.
No. Name
1 Media loading lever
To Next Page
