Appendix VJ-1324X OPERATION MANUAL
252 8.1 Product specifications
8.1 Product specifications
8.1.1 Printer specifications
Items Specification
Model name VJ-1324X
Printing method On-demand piezo drive system
Drive system Firmware servo/DC motor drive
Media feed system Multipoint pressurizing grid roller system
Media fixing system Pressurization roller down system by manual lever
Media feed/ejection Roll media Rear feed/Front ejection
Roll media outer diameter 150 mm or less
Roll media weight 19 kg or less
Maximum media width 1,371 mm
Minimum media width 210 mm
Maximum media thickness 0.3 mm (when the head height is Low) / 1.3 mm (when the head height is
High)
Maximum printable media width 1,361 mm
Print margin Roll media Front: 30 mm, Back: 5 mm (40 mm at the roll media end), Left: 5 to 25 mm,
Right: 5 to 25 mm
Media cut system Horizontal automatic cut system/manual cut system
Head height adjustment Two adjustable positions of Low/High
CPU 64-bit RISC CPU
Memory 128MB
Command MH-RTL (RTL-PASS)
Interface Network interface (Ethernet IEEE 802.3)
Ink Supply system Supplied through tubes from four-color independent cartridges
Cartridges Black, Cyan, Magenta, Yellow: 220 ml ± 5 ml each
(1,000 ml ± 5 ml when the optional high capacity pack adapter is used)
Environmental
condition
Operating condition Temperatures: 20 ºC to 32 ºC
Humidity: 40% to 60%, No condensation
Printing accuracy
coverage
Temperatures: 22 ºC to 30 ºC
Humidity: 40% to 60%, No condensation
Change rate Temperature: within 2ºC per hour
Humidity: within 5 % per hour
Archiving condition
(Ink not charged)
Temperature: -20 ºC to 60 ºC
Humidity: 20 % to 80 %, No condensation
Storage life: six months
Archiving condition
(Ink charged)
Temperature: -10 ºC to 40 ºC
Humidity: 20 % to 80 %, No condensation
Storage life: four days (32 º or higher)
