VJ-1324X OPERATION MANUAL Maintenance
6.2 Cleaning the printer 225
7. When some foreign substance such as dust or ink clump is attached, use the cleaning stick to remove
it.
8. Close the left maintenance cover.
• Close the cover firmly until it is locked.
No. Name
1 Around the print head
2 Head guide
3 Nozzles
4 Cleaning stick
No. Name
1 Maintenance cover
2
2
1
3
4
4
