T
r
oubleshooting
VJ-1324X OPERA
TION MANUAL
240
7.1 Malfunctions and failur
es
(6) Printing lines ar
e duplicated or p
atchy
No.
Possible cause
Remedy
Reference
1
Is the nozzle in good condi
tion?
Perform Head cleaning.
6.2.3 Head
cleaning
2
Is the head height set to High?
Return the head
height to “Low”.
4.2.5 Head
height adjustment
239
241
Table of Contents
1 Safety instructions
13
1.1 Types and meanings of warnings
14
1.2 Important safety instructions
15
1.3 Warning labels
18
1.3.1 Handling the warning labels
18
1.3.2 Location and type of warning labels
19
1.4 Operating Instruction Labels
20
1.4.1 Cautions on Handling the Operating Instruction Labels
20
1.4.2 Locations and Types of Operating Instruction Labels
20
2 Product overview
21
2.1 Features
22
2.2 Names of parts and functions
23
2.2.1 Front section
23
2.2.2 Rear section
24
2.2.3 Operation panel
25
2.2.4 Ink level indicator
29
2.2.4.1 Estimated Ink level graphic
30
2.3 Printer status
31
2.3.1 Normal
31
2.3.2 Setup menu display
31
2.3.3 Changing printer status
31
3 Before using
33
3.1 Power cable connection
34
3.2 Turning the power ON/OFF
38
3.2.1 Turning the power ON
38
3.2.2 Turning the power OFF
39
3.3 Installing ink cartridges
41
3.3.1 Installing 220 ml ink cartridges
43
3.3.2 Installing high capacity pack adapters (option)
47
3.3.3 When using the high capacity pack adapter for the printer whose ink is charged for the first time
51
3.4 Loading media
52
3.4.1 Loading roll media
52
3.4.2 Setting Roll Media
55
3.4.3 Setting the User Type Setting
59
3.5 Test print
61
3.5.1 Nozzle check
64
3.5.2 Mode print
65
3.5.3 Setup print
66
3.5.4 Palette print
67
3.6 Adjust Print
68
3.6.1 Standard Adjust Print
69
3.6.1.1 Standard Confirmation Pattern
70
3.6.1.2 Standard Rough Adjustment Pattern
75
3.6.1.3 Standard Micro Adjustment Pattern
79
3.6.2 Custom Adjustment Pattern
83
3.6.2.1 Custom Confirmation Pattern
84
3.6.2.2 Custom Rough Adjustment Pattern
90
3.6.2.2.1 Rough Pattern ALL
90
3.6.2.2.2 Rough Pattern A to F
94
3.6.2.3 Custom Micro Adjustment Pattern
97
3.6.2.3.1 Fine Pattern ALL
97
3.6.2.3.2 Fine Pattern A to F
101
3.7 Connecting the printer to PC
104
3.7.1 System requirements
104
3.7.2 Preparing cables
104
3.7.3 Connecting a network interface cable
105
4 Handling the printer
107
4.1 Print flow chart
108
4.2 Media
109
4.2.1 Media type
109
4.2.2 Cautions on handling media
109
4.2.3 Precaution on storing media
110
4.2.4 Printing area
110
4.2.5 Head height adjustment
110
4.2.5.1 When raising the print head
111
4.2.5.2 When returning the print head to the original position
113
4.2.6 Media feed adjustment
115
4.3 Menu setups on the operation panel
120
4.3.1 Menu setup procedure
120
4.3.2 Panel setup menu overview
122
4.4 Operating from the operation panel
123
4.4.1 Feeding media
123
4.4.2 Stopping printing operation
124
4.4.3 Cutting media
125
4.4.4 Cutting media manually
126
4.4.5 Changing and confirming settings while printing
127
4.4.5.1 Procedure for changing and confirming settings while printing
127
4.4.5.2 Settings that can be changed or confirmed while printing
128
4.4.6 Pausing printing
129
4.4.7 Start Printing during Warm up
130
4.4.8 Normal Display while Printing
131
Panel setup menu
133
5.1 Setup menu
134
5.1.1 User Type menu
137
5.1.1.1 User Type menu
138
5.1.1.1.1 Print Mode menu
139
5.1.1.1.2 Effect menu
141
5.1.1.1.3 Adjust Print menu
142
5.1.1.1.4 Dist.Adj menu
144
5.1.1.1.5 Pre-heater menu
146
5.1.1.1.6 Platen heater menu
147
5.1.1.1.7 Dryer menu
148
5.1.1.1.8 Vacuum Fan menu
148
5.1.1.1.9 Media thickness menu
149
5.1.1.1.10 User Copy menu
150
5.1.2 Spitting menu
151
5.1.2.1 Spitting Pass count menu
153
5.1.3 Side Margin menu
155
5.1.4 Media Initial menu
156
5.1.5 Media Width menu
157
5.1.6 Output Mode menu
158
5.1.6.1 Ink Drying Time Menu
159
5.1.6.2 Page Gap menu
160
5.1.7 Method of Cut menu
160
5.1.7.1 Cut Pressure menu
161
5.1.8 Origin menu
161
5.1.9 Prev. Stick menu
163
5.1.10 StandbyHeating menu
163
5.1.11 Head Travel menu
164
5.1.12 Multi Strike menu
164
5.1.13 Strike Wait menu
165
5.1.14 Slant Check menu
165
5.1.15 Auto Cleaning menu
166
5.1.15.1 Idle Auto Cleaning
167
5.1.15.2 Printing Mode Auto Cleaning
168
5.1.15.3 Pre-printing Mode Auto Cleaning
169
5.1.16 Ink Status menu
170
5.1.16.1 SmartChip menu
171
5.1.17 Roll Length menu
171
5.1.17.1 Roll Length menu
172
5.1.17.2 Print Stop menu
173
5.1.17.3 Near End menu
174
5.1.18 Longstore menu
174
5.1.19 CR Maintenance menu
175
5.1.20 Initialization menu
175
5.1.21 Life Times menu
176
5.1.22 IP Address menu
176
5.1.23 Subnet Mask menu
177
5.1.24 Gateway menu
177
5.1.25 Header Dump menu
178
5.1.26 Start Feed Menu
179
5.1.27 Heater Control menu
179
5.1.28 Alert Buzzer menu
180
5.2 Test Print Menu
181
5.3 Cleaning menu
182
5.4 Menu Option menu
183
5.5 Version menu
186
5.6 Sleep Mode menu
187
5.6.1 Timer Setting menu
188
5.6.2 Sleep Mode Start menu
189
5.7 Display menu
190
5.7.1 Language menu
190
5.7.2 Temperature menu
190
5.7.3 Length menu
191
5.7.4 Remain Ink menu
191
5.8 Job Status Menu
192
6 Maintenance
193
6.1 Replacing consumable components
194
6.1.1 Replacing ink cartridges
194
6.1.2 Replacing Roll Media
200
6.1.3 Replacing Cutter
203
6.2 Cleaning the printer
210
6.2.1 Cleaning the outer case
211
6.2.2 Cleaning the inside of the printer
212
6.2.3 Head cleaning
214
6.2.4 Cleaning the cleaning wiper
215
6.2.5 Cleaning around the print head
220
6.3 Disposal of waste fluids
227
6.4 Moving or transporting the printer
229
6.4.1 Moving the printer
229
6.4.2 Transporting the printer
231
7 Troubleshooting
233
7.1 Malfunctions and failures
234
7.1.1 Problems in installation and introduction
234
7.1.2 Cannot print at all
235
7.1.3 Media-related troubleshooting
236
7.1.4 Printing-related troubleshooting
238
7.2 Error messages
241
7.2.1 Status messages
241
7.2.2 Message type error display and remedies
243
7.2.3 Error requiring restart
246
7.3 The media is jammed
247
7.4 Smartchip Recovery
250
7.4.1 When the message “[***] S/C Recog. Err.” appears
250
7.4.2 When the message “[**] Check Color ->E” appears
250
8 Appendix
251
8.1 Product specifications
252
8.1.1 Printer specifications
252
8.2 Interface specification
254
8.2.1 Network interface specification
254
8.3 Options/Supply list
255
9 Setup menu diagram
257
