VJ-1324X OPERATION MANUAL Product overview
2.2 Names of parts and functions 27
(2) Display section
7[Forward↓] key Media is fed in the forward direction. —
[–] key — • Changes to the previous item in the
displayed setting.
• The setting is changed to the forward
direction.
• The numeric value is decreased during
numerical input.
8 [Power] key Turns the printer ON and OFF. Turns the printer ON and OFF.
No. Name Color Status Description
9 Power lamp Blue Lamp
ON
Power ON.
Lamp
blinks
• Receiving and analyzing the data.
• Performing media initial operation.
Lamp
OFF
Power OFF.
10 Error lamp Orange Lamp
ON
An error has occurred.
Error content is displayed on the LCD.
Lamp
blinks
The remaining amount of ink is low.
Lamp
OFF
There is no error.
11 High lamp Green Lamp
ON
The head height is set to High.
Lamp
OFF
The head height is set to Low.
12 Low lamp Green Lamp
ON
The head height is set to Low.
Lamp
OFF
The head height is set to High.
13 Take Up lamp Green Lamp
ON
Media ejection mode is set to “Take-up”.
Lamp
OFF
Media ejection mode is set to “Off” or “Auto cut”.
14 Auto Cut lamp Green Lamp
ON
Media ejection mode is set to “Auto cut”.
Lamp
OFF
Media ejection mode is set to “Off” or “Take-up”.
15 Long lamp Green Lamp
ON
• Cleaning mode is set to Long.
• When the Normal lamp is also on, Cleaning mode is set to Short.
Lamp
OFF
Cleaning Mode is set to Normal.
