VJ-1324X OPERATION MANUAL Before using
3.4 Loading media 57
5. While holding the edge of the media, rewind the roll media a little by turning the scroller by hand
and eliminate any slack or slant.
6. Lower the media loading lever.
• When loading the new roll media, cut the front edge of the media if it is not straight.
4.4.3 Cutting media
No. Name
1 Roll media
2 Scroller
No. Name
1 Media loading lever
