Before using VJ-1324X OPERATION MANUAL
76 3.6 Adjust Print
• A rough adjustment pattern is printed.
(The printer starts printing after warming up is complete.)
• For the rough adjustment pattern, the same patterns will be printed on both sides and center of
the media.
4. Check the both ends and the center of the print result that printed with Adjust pattern, and select the
number from 1 to 11 that is not out of alignment.
• “9” is selected in the next printing sample.
• “6” is the current setting value.
• When the line is aligned, the bold line on its left side does not have a white vertical line in the
middle.
Pattern name
Current Print Mode
1234567891011
Q3/Q4
B
8910
Not adequate Adequate
Not adequate
To Next Page
