- 4-
Bodywork
C
Fairing side panel removal
Remove the seven fixing bolts (1) situated on the right
fairing side panel.
Remove the fairing side panel, sliding it off from the
front side.
Repeat the operation for the left fairing side panel.
To separate the air manifold from the side panels,
removing the two fixing screws (2).
1
2
