- 46 -
Electrical system
E
LICENCE PLATE LIGHT
If the number plate light bulbs do not function, check
the condition of fuse 1 in the fuse box; if these are ok,
replace the bulb by following the procedure described
in Section B - Maintenance.
TURN INDICATORS
In the event that turn indicators do not work, check the
conditions of following fuse:
- MY10 -> MY12: Fuse 1
- MY13: Fuse 6
If the fuse is ok, check the continuity between Gr-Bk/W
(Green-Black/White) and Gr-Y/W (Green-Yellow/White)
wires respectively for left and right indicators on the
connector of the left switch.
STOP AND REAR LIGHT
In the event that tail lights and brake lights do not work,
check the conditions of the following fuses:
- MY10->MY12: Fuse 7 (stop) / Fuse 1 (rear light)
- MY13: Fuse 6 (stop) / Fuse 3 (rear light)
If these are ok, check the continuity between the con-
nector poles of the related controls by pulling the cor-
responding lever.
