- 8 -
Electrical system
E
1 CPU
2 Number plate light
3 Right indicator
4 Left indicator
5 Diagnostic connector
6 Main relay
7 Rear and stop light
8 Neutral switch
9-10 Battery
11 Fuel probe – pump
12 R.p.m. sensor
13 Coil
14 Coil
15 Coil
16 Coil
17 Alternator
18 Speed sensor
19 Solenoid starter
20 General feed relay
21 Intermittence
22-23 Upper injectors
24-25 Upper injectors
26 Throttle potentiometer
27 Water temperature sensor – CPU
28 Oil switch
29 Electric fan
30 Fuses
31 Electric fan
32 Side stand switch
33 Rear stop switch
34 Ignition switch
35 Safety and Front stop switch
36 Right indicator
37 Front headlight
38 Instrument panel
39 Air pressure sensor
40 Left indicator
41 Horn
42 Air temperature sensor
43 Light switch
44 Relay ballast headlight
45 Exhaust valve actuator
46 Immobilizer Antenna
47 Fan relay
48 Battery recharge
49 Clutch switch
50 Starter motor
51 Engine earth
52 Voltage regulator
53 TSS valve
54 Additional CAN socket
55 Angular switch
56 Secondary air system
57 Lambda sensor
58-59 Lower injectors
60-61 Lower injectors
Parts list
Ref. Description
Parts list
Ref. Description
Wiring colour code
Letter(s) Colour
Fuses list
Ref. Amps Use
(A)
R Red
Y Yellow
B Blue
G Green
W White
Bk Black
P Pink
V Violet
Sb Sky blue
Gr Grey
O Orange
Br Brown
In combined colors, background and marking colors have
been pointed out. E.g.: Br/Bk.
F1 15 Speed sensor - Lambda sensor -
Intermittence - Solenoid starter -
Solenoid secondary air
F2 15 High beam
F3 15 Ballast front light
F4 15 Coils
F5 15 Electric fans
F6 15 Fuel pump - Injectors
F7 15 Central unit - Stop light
F8 40 Battery recharge
F9 40 Battery recharge supply
