BATTERY ASSEMBLY
1) Perform the initial charge of the battery according to
the instruction shown in page 13.
2) Insert the motorcycle key in the rear lock. Rotate the
key clockwise while removing the pillion. Then remove the
rider’s saddle as shown in the picture.
3) Remove the frame plate (1) to facilitate the following
operations.
4) Remove the solenoid starter (2) securing screw to
allow the insertion of the battery.
- 14 -
Electrical system
E
1
2
