Cooling system
L
- 20 -
Insert the thermostat cover on the engine.
Tighten the three fixing screws (1) to the prescribed
torque pressure.
Torque pressure: 10 N·m
Replace the tubes on the thermostatic valve and fasten
the relative clic clamps.
10 N•m
WATER RADIATOR VEHICLE UNIT ASSEMBLY
Insert the upper right radiator mount into the peg on the
frame (right side).
Reassemble the radiator unit in the opposite order of
disassembly.
