MV Agusta F4 S - Steering Assembly

Suspension and wheels
F
- 29 -
STEERING ASSEMBLY
I
A
D
H
F
C
B
D
G
E
D
B
D
L
L
ABCDEFGH I L
N· m 120 ÷ 125 16 ÷ 18 8 ÷ 10 4 ÷ 6 22 ÷ 24 22 ÷ 24 8 ÷ 10
In contact
-F4 MY13) +10°
18 ÷ 22
(F4 RR)
Kg· m
ft· lb
Torque
pressure
Operation
270
