Brakes
- 23 -
H
Screw in the screws lightly, proceeding in a star-like
mode.
Continuing in a star-like mode, tighten the screws to
the prescribed torque pressures.
Torque pressures: 23-25 N·m
Be careful to reassemble the discs in the original posi-
tions (it is advisable to mark them by applying an adhe-
sive label).
This operation is important so that a good
contact between the brake discs and the rel-
ative pads.
Proceed by reassembling the parts in the reverse order
of removal. Consult chapter F “Suspension and
wheels” for further information.
23÷25 N•m
FRONT BRAKE DISC ASSEMBLY
Thoroughly clean the contact surfaces of the discs and
the wheel.
Accurately grease all relative surfaces of the disc
before reassembling.
The following operation is to be carried out on all mod-
els.
Apply thread-locking fluid to the five fixing screws of
the disc.
Recommended product: Loctite 243
