FRAME PLATE REMOVAL
Cut the chain as described in chapter F "Suspension
and Wheels."
Remove the exhaust manifold support screw from the
right side of the motorcycle.
Disconnect the rear brake pump connector.
Remove the rear brake pump fixing screws.
