Suspension and wheels
F
- 69 -
REAR WHEEL HUB
H
L
M
C
D
E
G
A
F
B
I
N
O
AB C D E F G H ILMN O
N· m 30÷35 20÷22 45÷50 200÷220 28÷32 220÷240 140 25 8 5÷7 18 18÷20
Kg· m
ft· lb
Torque
pressure
Operation
243 243 270270243
Description F4 S F4 FT F4 MY13 F4 R MY12 F4 R MY13 F4 RR
REAR WHEEL
Material Forged Forged Forged
Aluminum alloy
aluminum alloy
Aluminum alloy Aluminum alloy
aluminum alloy aluminum alloy
Dimensions 6,00” x 17” 6,00” x 17” 6,00” x 17” 6,00” x 17” 6,00” x 17” 6,00” x 17”
REAR TYRE
Dimensions 190/55-ZR 17 190/55-ZR 17 200/55-ZR 17 190/55-ZR 17 200/55-ZR 17 200/55-ZR 17
(75W) (75W) (78W) (75W) (78W) (78W)
Brand and type PIRELLI - Diablo Supercorsa SP
PIRELLI - Diablo Supercorsa SP
DUNLOP - Sportmax Qualifier RR
Rear tyre At a speed lower than 300km/h: 2.3 bar (33 psi)
pressure: At a speed higher than 300km/h: 2.9 bar (42 psi)
