FRAME REMOVAL PRELIMINARY OPERATIONS
Support the motorcycle with the aid of the following
kickstands:
- Code 800092642: Rear kickstand
- Code 800095807: Front kickstand
- Code 8000B4303: Engine support
Remove the following components in order:
- Front mudguard
- Front brake callipers
- Front wheel
- Central air manifold
as described in chapters F - "Suspension and Wheels"
and C "Superstructures."
Besides, remove the lower airbox complete with TSS
system as described in the Engine Workshop Manual.
- 16 -
Frame
G
