Maintenance
- 37 -
B
Maintenance
FUEL TUBE / FITTINGS
Check for leaks
g First 1000 kilometres and then
every 6000 kilometres
Carry out a visual check for eventual leakages from the
fuel feed tubing and the unions (see figure).
Substitute damaged parts if leaks or evaporation are
found.
FUEL TUBE ASSEMBLY
Substitute
g At least every three years
The procedure to follow in the case of substitution of
the feed tubing is as follows:
Remove in this order:
• Fairing side panels
• Under-engine fairing
• Rear side panels
• Fuel tank side panels
• Fuel tank
• Airbox side panels
• Air filter compartment
Press the two stop tabs simultaneously and take out
the tube.
Insert the new fuel tube onto the union of the throttle
body, until it has locked into place.
UTILISE ONLY NEW PARTS.
