Brakes
- 3-
H
FRONT BRAKE SYSTEM
ABCDEFGH
N·m 288÷10 40 ÷ 42 23 ÷ 26 16 ÷ 18 8 ÷ 10 23 ÷ 25
Kg·m
ft·lb
Torque
pressure
Operation
G
H
H
F
C
B
B
243
A
D
E
C
Description F4 S F4 Frecce Tricolori F4 MY13 F4 R F4 RR
FRONT BRAKE
Type Dual floating disc with steel braking band
Ø discs (mm) 320 320 320 320 320
Disc flange Aluminium Aluminium Aluminium Aluminium Aluminium
Master cylinder Axial-type Axial-type Axial-type Axial-type Radial-type
Calipers (Ø pistons mm) Radial-type, single-piece
Radial-type, single-piece with 4 pistons (Ø 34) with 4 pistons
(MY12: Ø 34 / MY13: Ø 30)
Front disc thickness (mm) 55555
Min. pad thickness (mm) 11111
It is advisable to remove the parts of the bodywork as described in the chapter "Bodywork" that could obstruct
normal operations, before proceeding with the overhaul of the front brake system.
