- 22 -
Brakes
H
Place the brake disc on a level surface with the milled
side face down and utilising a micrometer gauge check
that the maximum oscillation of the disc reached dur-
ing a rotation of 360° does not exceed 0.3 mm.
Utilise a micrometer gauge for this check
If the measurements are below the mini-
mum, substitute the component with a new
one.
This operation must be carried out on both front discs.
FRONT BRAKE DISC REMOVAL
Take down the front wheel as described in chapter F
"Suspensions and Wheels".
Using two special spanners (see chapter F "Suspen-
sions and Wheels"), remove the front wheel spindle.
Special tool 800092872
Place the wheel in a horizontal position and remove
the five screws of each disc proceeding in a star-like
mode for the removal.
Visually check the discs for lines or score marks.
