- 12 -
Electrical system
E
1 CPU
2 Number plate light
3 Rear right indicator
4 Front left indicator
5 Diagnostic connector
6 Main relay
7 Rear and stop light
8 Neutral switch
9-10 Battery
11 Fuel probe – pump
12 R.p.m. sensor
13 Coil
14 Coil
15 Coil
16 Coil
17 Alternator
18 Rear speed sensor
19 Solenoid starter
20 General feed relay
21 Intermittence
22-23 Upper injectors
24-25 Upper injectors
26 Throttle potentiometer
27 Water temperature sensor – CPU
28 Oil switch
29 Electric fan
30 Fuses
31 Electric fan
32 Side stand switch
33 Rear stop switch
34 Ignition switch
35 Safety and Front stop switch
36 Front right indicator
37 Front headlight
38 Instrument panel
39 Air pressure sensor
40 Rear left indicator
41 Horn
42 Air temperature sensor
43 Light switch
44 Relay ballast headlight
45 Exhaust valve actuator
46 Immobilizer Antenna
47 Fan relay
48 Battery recharge
49 Clutch switch
50 Starter motor
51 Engine earth
52 Voltage regulator
53 TSS valve
54 Front speed sensor
55 Position lights
56 Quick Shift
57 Lambda sensor
58-59 Lower injectors
60-61 Lower injectors
62 TPMS connection
63 Lean angle sensor
64 DBW (Drive by Wire) position
65 DBW (Drive by Wire) actuator
66 Suspension management unit
(only for F4 RR)
67 Water temperature sensor – Fan
68 SET/OK button
69 ABS Unit
Parts list
Ref. Description
Parts list
Ref. Description
Wiring colour code
Letter(s) Colour
Fuses list
Ref. Amps Use
(A)
R Red
Y Yellow
B Blue
G Green
W White
Bk Black
P Pink
V Violet
Sb Sky blue
Gr Grey
O Orange
Br Brown
In combined colors, background and marking colors have
been pointed out. E.g.: Br/Bk.
F1 15 Fuel pump - Coils
F2 7.5 Lambda sensor - Injectors
F3 7.5 Position lights - License plate light
F4 15 Front light ballast
F5 15 Main relay - Speed sensors -
Instrument panel - Lean angle sensor -
TPMS - Suspension management unit
F6 15 Intermittence - Horn - Stop light -
Diagnostic - TSS - High beam
F7 15 Electric fans
F8 40 Battery recharge
F9 40 Battery recharge supply
F10 15 ABS System
F11 25 ABS System
