- 2-
Diagnostic
O
ELECTRICAL COMPONENTS
CHARGING SYSTEM
Battery warning light on Alternator broken Replace
Alternator connection defective Check
Voltage regulator connection defective Deoxidize/Repair
Voltage regulator broken Replace
Battery faulty Replace
Recharge fuse (40A) blown Replace
Recharge fuse connection defective Deoxidize/Repair
Battery connections oxidized Deoxidize/Repair
POWER SUPPLY FOR 12V SERVICES
No function enabled Ignition switch broken Replace
Ignition switch connection defective Deoxidize/Repair
Main relay broken Replace
Main relay connection defective Deoxidize/Repair
ELECTRIC STARTER
Electric starter does not work Start-up engine does not work, Tilt sensor fault Replace
Low battery charge Recharge
Neutral position sensor broken Replace
Clutch pump switch broken Replace
Starter motor broken Replace
Starter button broken Replace
Right-hand switch unit connection faulty Deoxidize/Repair
Starting relay switch broken Replace
Power cable connections faulty Deoxidize/Repair
Power unit failure Replace
COOLING SYSTEM
Electric fans do not work MY10->MY12: Fuse 5 blown Replace
MY13: Fuse 7 blown Replace
MY10->MY12: Fuse 5 connection faulty Deoxidize/Repair
MY13: Fuse 7 connection faulty Deoxidize/Repair
Fan relay broken Replace
Electric fan broken Deoxidize/Repair
LIGHTS/INDICATORS
Rear tail lights not working MY10->MY12: Fuse 1 blown Replace
MY13: Fuse 3 blown Replace
MY10->MY12: Fuse 1 connection faulty Deoxidize/Repair
MY13: Fuse 3 connection faulty Deoxidize/Repair
Ignition switch broken Replace
Ignition switch connection faulty Deoxidize/Repair
Device damaged Replace
High beam does not work MY10->MY12: Fuse 2 blown Replace
MY13: Fuse 4 blown Replace
MY10->MY12: Fuse 2 connection faulty Deoxidize/Repair
MY13: Fuse 4 connection faulty Deoxidize/Repair
Bulb burnt out Replace
Low beam does not work MY10->MY12: Fuse 3 blown Replace
MY13: Fuse 4 blown Replace
MY10->MY12: Fuse 3 connection faulty Deoxidize/Repair
MY13: Fuse 4 connection faulty Deoxidize/Repair
Bulb burnt out Replace
Bulb connections faulty Deoxidize/Repair
Ballast control unit damaged Replace
Lights switch broken Replace
Lights switch connection faulty Deoxidize/Repair
Ballast relay broken Replace
Ballast relay connection faulty Deoxidize/Repair
