Frame
- 23 -
G
PLUG-TOP COIL DISASSEMBLY
(MY10 -> MY12)
Remove the wiring fixing clamp on the right side of the
frame.
Disconnect the secondary air valve connector.
Protect suction ducts with adhesive tape to prevent dirt
intrusion inside the cylinders.
Remove the following components in order:
- Steering head
- Acoustic warning signal
- Right/left handlebars
- Right/left front forks
- Steering sleeve
as described in chapter F - "Suspension and Wheels."
