MV Agusta F4 S - Steering Sleeve Housing Check (F4 S - Ft - Rr)

Frame
- 39 -
G
Measure ovalisation in different points as shown in the
diagram.
Steering sleeve housing check
(F4 S - FT - RR)
Check the diameter and for any ovalisation on the
steering sleeve bevel housing, at 3 mm from the upper
and lower edge as shown in the drawing here to the
side.
