- 16 -
Bodywork
C
To disconnect the fuel tube, press and slide
the retaining slide as shown in the figure.
Disconnect the electrical system connector.
Disassemble the duct cover panels
Remove the two connecting screws (1) of the right
panel (2) of the frame.
2
1
