Bodywork
Central manifold disassembly
Remove the flashing relay (1) toward the rear part.
Remove the two fixing screws (2) and remove the cen-
tral manifold (3).
Front mudguard disassembly
Unscrew and remove the 4 fixing screws (1) on the
mudguard (2 per side).
- 29 -
C
1
2
3
1
