- 6-
Maintenance
B
TECHNICAL DATA (MY13)
Description F4 F4 R F4 RR
TRANSMISSION
Type Removable, six-speed gearbox with constant-mesh gears
Gear ratios (total ratios)
1
st
2.643 (12.341) 2.643 (12.341) 2.643 (12.341)
2
nd
2.062 (9.631) 2.062 (9.631) 2.062 (9.631)
3
rd
1.722 (8.042) 1.722 (8.042) 1.722 (8.042)
4
th
1.500 (7.004) 1.500 (7.004) 1.500 (7.004)
5
th
1.318 (6.155) 1.318 (6.155) 1.318 (6.155)
6
th
1.190 (5.559) 1.190 (5.559) 1.190 (5.559)
FRAME
Type CrMo steel tubular CrMo steel tubular CrMo steel tubular
trellis (MAG welded) trellis (MAG welded) trellis (TIG welded)
Swingarm pivot plates Aluminium alloy Aluminium alloy Aluminium alloy
FRONT SUSPENSION
Type “Upside down” telescopic hydraulic fork “Upside down” telescopic hydraulic fork ÖHLINS Nix EC - “Upside down” telescopic
with external and separated adjustment with external and separated adjustment hydraulic fork with electronic adjustment
of rebound and compression damping of rebound and compression damping of rebound and compression damping
and of spring preload and of spring preload and of spring preload
Ø stems (mm) 50 50 43
Travel on leg axis (mm) 120 120 120
REAR SUSPENSION
Type Progressive, single shock absorber ÖHLINS TTX progressive, single ÖHLINS TTX progressive, single shock
with rebound-compression (High/Low shock absorber with rebound- absorber with electronic adjustment of
speed) damping and spring preload compression damping and rebound-compression damping
adjustment spring preload adjustment and spring preload
Wheel travel (mm) 120 120 120
Swingarm Aluminium alloy Aluminium alloy Aluminium alloy
FRONT BRAKE
Type Dual floating disc with Dual floating disc with Dual floating disc with
steel braking band steel braking band steel braking band
Ø discs (mm) 320 320 320
Disc flanges Aluminium Aluminium Aluminium
Master cylinder Axial-type Axial-type Radial-type
Calipers (Ø pistons mm) Radial-type, single-piece Radial-type, single-piece Radial-type, single-piece
with 4 pistons (Ø 34) with 4 pistons (Ø 34) with 4 pistons (Ø 30)
REAR BRAKE
Type Single steel disc Single steel disc Single steel disc
Ø disc (mm) 210 210 210
Caliper (Ø pistons mm) 4-piston (Ø 25.4) 4-piston (Ø 25.4) 4-piston (Ø 25.4)
FRONT RIM
Material Aluminium alloy Forged aluminium alloy Forged aluminium alloy
Dimensions 3,50” x 17” 3,50” x 17” 3,50” x 17”
REAR RIM
Material Aluminium alloy Forged aluminium alloy Forged aluminium alloy
Dimensions 6,00” x 17” 6,00” x 17” 6,00” x 17”
TYRES
Front 120/70-ZR 17 (58 W) 120/70-ZR 17 (58 W) 120/70-ZR 17 (58 W)
Rear 200/55-ZR 17 (78 W) 200/55-ZR 17 (78 W) 200/55-ZR 17 (78 W)
Brand and type PIRELLI - Diablo Supercorsa SP PIRELLI - Diablo Supercorsa SP PIRELLI - Diablo Supercorsa SP
Tyre pressure (*) Per velocità infe- Per velocità supe- Per velocità infe- Per velocità supe- Per velocità infe- Per velocità supe-
riori a 300 km/h riori a 300 km/h riori a 300 km/h riori a 300 km/h riori a 300 km/h riori a 300 km/h
Front 2.3 bar (33 psi) 2.5 bar (36 psi) 2.3 bar (33 psi) 2.5 bar (36 psi) 2.3 bar (33 psi) 2.5 bar (36 psi)
Rear 2.3 bar (33 psi) 2.9 bar (42 psi) 2.3 bar (33 psi) 2.9 bar (42 psi) 2.3 bar (33 psi) 2.9 bar (42 psi)
ELECTRICAL SYSTEM
Equipment voltage 12V 12V 12V
Headlight bulb PHILIPS XenStart D1S 35W PHILIPS XenStart D1S 35W PHILIPS XenStart D1S 35W
Tail light bulb 4 diodes - 12V 0.6W 4 diodes - 12V 0.6W 4 diodes - 12V 0.6W
Battery 12V - 8,6Ah 12V - 8,6Ah 12V - 8,6Ah
Alternator 350 W at 5000 rpm 350 W at 5000 rpm 350 W at 5000 rpm
BODYWORK
Fairing Thermoplastic material Thermoplastic material Thermoplastic material
Front fairing Thermoplastic material Thermoplastic material Thermoplastic material
Rear side panels Thermoplastic material Thermoplastic material Thermoplastic material
Fuel tank Thermoplastic material Thermoplastic material Thermoplastic material
Air scoops Thermoplastic material Thermoplastic material Thermoplastic material
Air box Thermoplastic material Thermoplastic material Thermoplastic material
Air box side panels Thermoplastic material Thermoplastic material Thermoplastic material
Front mudguard Thermoplastic material Thermoplastic material Thermoplastic material
Chain guards Thermoplastic material Thermoplastic material Thermoplastic material
Exhaust pipe guard Aluminium Aluminium Aluminium
Heat shield Thermoplastic material Thermoplastic material Thermoplastic material
License-plate holder Thermoplastic material Thermoplastic material Thermoplastic material
* : If tyre brands other than those recommended are used, refer to the tyre pressure indicated by the manufacturer on the tyre side wall.
