Suspension and wheels
F
- 45 -
Rear shock absorber disassembly
Remove the seats, side panels, tank and rear panels
as described in Chapter C "Fairings".
Lift up the rear part of the motorcycle (with the specific
lifter) high enough to take the load off the shock
absorber.
1
Slacken the upper screw (1) of the shock absorber.
2
Remove the lower screw (2) of the shock absorber.
