Brakes
Before fitting the pads back in, make sure the plate
rests against its stop. If it does not, push it down, as
shown in the Figure.
Fit either pad through the midst of the front back caliper
opening, then push it towards its pistons. Do the same
with the other pad.
Fit the caliper back in but do not tighten the screws.
Operate the front brake lever to position the pistons
(pushing against the pads).
While pulling the front brake lever, tighten the caliper
screws to the right torque.
Torque pressure calipers: 40
÷42 N·m
- 5-
H
40÷42 N•m
