Maintenance
- 33 -
B
Maintenance
Remove the filter cartridge and replace with a new one.
Insert the upper tube in the new cartridge and fix with
a clamp taken from the new kit, using the special tool.
Pneumatic pincer: Oetiker HO 3000 ME
Insert the lower tube in the new cartridge and fix with a
clamp taken from the new kit, using the special tool.
Pneumatic pincer: Oetiker HO 3000 ME
