Maintenance
- 59 -
B
Regulationg At the first 1000 kilometres and then
every 6000 kilometres.
To adjust the chain tension, proceed as follows:
Slightly slacken the two screws of the rear wheel hub.
Loosen the 2 rear wheel hub screws.
Using the special spanner as indicated in the figure,
move the eccentric adjuster nut backwards or forwards
respectively slackening or tightening the chain, until
the correct play is reached (as described previously).
Maintenance
28÷32 N•m
Successively tighten the screws of the rear wheel hub
to the torque pressure indicated as follows:
Tighten the screws to the specified torque
in several steps and in an alternate pattern.
Rear hub eccentric adjuster screw torque
pressure: 28 ÷ 32 N·m
Grease only the first threads.
NOTE
